Analysis of anchorage control in different vertical skeletal pattern

doi:10.3877/cma.j.issn.1674-1366.2011.06.0012

Abstract

Abstract:

Objective

To study the anchorge effects of lower molars in different vertical skeletal patterns by light-segmented archwire.

Methods

Fifty cases with different vertical skeletal pattern were selected and two lower first bicuspids were extracted in all cases.In the first half year， lower cuspids were distalized with light-segmented archwire， and lower incisors were in the physiologic drift stage.Cephalograms and study models were recorded before and six months after the treatment， respectively.Parameters such as L6-MP， L6E-RL and L4 Space were measured and the data were analyzed by SPSS 10.0.

Results

L6-MP angles were different among different vertical skeletal patterns.L6-MP angle was decreased from 81.8° to 79.6° in high-angle skeletal pattern， from 83.1° to 82.0° in normal-angle pattern， and from 87.0° to 86.2° in low-angle pattern.

Conclusion

Vertical skeletal pattern is correlated with the angle of the lower first molar but not correlated with the value of the lower first molar adjustment.

Key words: Lower first molar, Vertical skeletal pattern, Light-segmented archwire

Xin-hua LU, Liping WU, Yue XU, Bin CAI. Analysis of anchorage control in different vertical skeletal pattern[J]. Chinese Journal of Stomatological Research(Electronic Edition), 2011, 5(06): 628-634.

/ / Recommend

Add to citation manager EndNote|Ris|BibTeX

URL: https://zhkqyxyjzz.cma-cmc.com.cn/EN/10.3877/cma.j.issn.1674-1366.2011.06.0012

https://zhkqyxyjzz.cma-cmc.com.cn/EN/Y2011/V5/I06/628

Figures/Tables 19

References 11

1	卢新华，蔡斌，吴莉萍，等.细丝片段弓移动尖牙的应用分析.华西口腔医学杂志， 2005，23（3）:244-246.
2	邹冰爽，曾祥龙，傅民魁.高角和低角病例的诊断、临床特征及正畸治疗特点.口腔正畸学， 1999，6（1）:39-42.
3	徐芸，段银钟，梁文勇，等，译.Tweed-Merrifield 标准方丝弓矫治理论与实用技术.天津:天津科技翻译出版公司， 1998:1-3.
4	Andria LM， Leite LP， Dunlap AM， et al.Mandibular first molar relation to variable lower face skeletal components.Angle Orthod，2007，77（1）:21-28.
5	Kuitert R， Beckmann S， van Loenen M， et al.Dentoalveolar compensation in subjects with vertical skeletal dysplasia.Am J Orthod Dentofacial Orthop， 2006，129（5）:649-657.
6	Klontz HA.The vertical dimension: the high-angle problem.World J Orthod， 2006，7（4）:336-344.
7	Knösel M， Engelke W， Attin R， et al.A method for defining targets in contemporary incisor inclination correction.Eur J Orthod， 2008，30（4）:374-380.
8	邹晖，赖仁发.下颌肌肉与垂直骨面型的关系及对正畸治疗的影响.广东牙病防治， 2007，15（6）:280-282.
9	李海涛，崔传江，卢恕来，等.不同垂直颅面结构安氏Ⅱ¹ 类错合牙嚼肌肌电活动变化.青岛大学医学院学报， 2010，46（1）:32-34
10	Jung MH， Yang WS， Nahm DS.Maxium closing force of mentolabial muscles and type of malocclusion.Angle Orthod， 2010，80（1）:72-79.
11	Sonnesen L， Bakke M.Molar bite force in relation to occlusion， craniofacial dimensions， and head posture in pre-orthodontic children.Eur J Orthod， 2005，27（1）:58-63.

测量项目	高角			均角			低角
测量项目	治疗前	6 个月	6 个月变化	治疗前	6 个月	6 个月变化	治疗前	6 个月	6 个月变化
SN-MP（°）	43.21 ± 3.64	43.48 ± 3.55	0.30 ± 1.37	34.29 ± 2.15	34.50 ± 2.36	0.23 ± 1.58	27.64 ± 4.67	27.53 ± 4.27	-0.14 ± 0.82
OP-FH（°）	19.90 ± 3.00	19.37 ± 3.06	-0.45 ± 0.97	15.72 ± 3.29	15.24 ± 3.16	-0.59 ± 1.07	12.15 ± 3.38	11.49 ± 3.61	-0.52 ± 1.09
L₆-MP（°）	81.81 ± 4.90	79.64 ± 4.21	-2.05 ± 2.86^a	83.07 ± 3.25	82.04 ± 3.07	-1.26 ± 2.22^a	86.95 ± 5.17	86.19 ± 6.14	-0.76 ± 2.49^a
L₆E-RL（mm）	23.46 ± 3.74	24.34 ± 3.33	1.02 ± 1.19^a	24.22 ± 4.09	25.46 ± 3.88	1.16 ± 0.89^a	24.56 ± 3.78	25.53 ± 4.13	0.97 ± 1.04^a
L₆A-RL（mm）	14.51 ± 4.94	15.85 ± 4.57	1.41 ± 1.64^a	17.05 ± 4.77	18.43 ± 4.45	1.38 ± 1.10^a	17.93 ± 4.96	19.12 ± 5.31	1.19 ± 0.65^a
L₆E-MP（mm）	35.99 ± 4.20	36.88 ± 3.92	0.96 ± 1.13^a	34.47 ± 3.35	35.23 ± 3.16	0.72 ± 0.49^a	35.01 ± 1.65	35.75 ± 1.93	0.74 ± 1.02^a
L₆A-MP（mm）	16.96 ± 4.62	18.03 ± 4.48	1.19 ± 1.06^a	15.71 ± 3.78	16.59 ± 3.58	0.83 ± 0.58^a	16.35 ± 1.90	17.21 ± 1.95	0.86 ± 0.99^a
L₄ 间隙（mm）	6.66 ± 0.75	1.58 ± 0.80	5.08 ± 1.24^a	6.68 ± 0.76	1.70 ± 0.87	4.98 ± 1.18^a	6.68 ± 0.64	1.87 ± 1.65	4.81 ± 1.38^a

测量项目	高角			均角			低角
测量项目	治疗前	6 个月	6 个月变化	治疗前	6 个月	6 个月变化	治疗前	6 个月	6 个月变化
SN-MP（°）	43.21 ± 3.64	43.48 ± 3.55	0.30 ± 1.37	34.29 ± 2.15	34.50 ± 2.36	0.23 ± 1.58	27.64 ± 4.67	27.53 ± 4.27	-0.14 ± 0.82
OP-FH（°）	19.90 ± 3.00	19.37 ± 3.06	-0.45 ± 0.97	15.72 ± 3.29	15.24 ± 3.16	-0.59 ± 1.07	12.15 ± 3.38	11.49 ± 3.61	-0.52 ± 1.09
L₆-MP（°）	81.81 ± 4.90	79.64 ± 4.21	-2.05 ± 2.86^a	83.07 ± 3.25	82.04 ± 3.07	-1.26 ± 2.22^a	86.95 ± 5.17	86.19 ± 6.14	-0.76 ± 2.49^a
L₆E-RL（mm）	23.46 ± 3.74	24.34 ± 3.33	1.02 ± 1.19^a	24.22 ± 4.09	25.46 ± 3.88	1.16 ± 0.89^a	24.56 ± 3.78	25.53 ± 4.13	0.97 ± 1.04^a
L₆A-RL（mm）	14.51 ± 4.94	15.85 ± 4.57	1.41 ± 1.64^a	17.05 ± 4.77	18.43 ± 4.45	1.38 ± 1.10^a	17.93 ± 4.96	19.12 ± 5.31	1.19 ± 0.65^a
L₆E-MP（mm）	35.99 ± 4.20	36.88 ± 3.92	0.96 ± 1.13^a	34.47 ± 3.35	35.23 ± 3.16	0.72 ± 0.49^a	35.01 ± 1.65	35.75 ± 1.93	0.74 ± 1.02^a
L₆A-MP（mm）	16.96 ± 4.62	18.03 ± 4.48	1.19 ± 1.06^a	15.71 ± 3.78	16.59 ± 3.58	0.83 ± 0.58^a	16.35 ± 1.90	17.21 ± 1.95	0.86 ± 0.99^a
L₄ 间隙（mm）	6.66 ± 0.75	1.58 ± 0.80	5.08 ± 1.24^a	6.68 ± 0.76	1.70 ± 0.87	4.98 ± 1.18^a	6.68 ± 0.64	1.87 ± 1.65	4.81 ± 1.38^a

测量项目	治疗前		6 个月		6 个月半年变化
测量项目	F	差异性	F	差异性	F	差异性
SN-MP（°）	59.37^a	L＜N＜H	59.01^a	L＜N＜H	0.39
OP-FH（°）	11.69^a	L＜N＜H	12.01^a	L＜N＜H	0.08
L₆-MP（°）	6.28^b	H，N＜L	9.68^a	H＜L	0.96
L₆E-RL（mm）	0.56		0.66		0.18
L₆A-RL（mm）	2.49		2.47		0.09
L₆E-MP（mm）	0.19		0.38		0.40
L₆A-MP（mm）	0.01		0.08		0.94
L₄ 间隙（mm）	0.43		0.77		0.43

测量项目	治疗前		6 个月		6 个月半年变化
测量项目	F	差异性	F	差异性	F	差异性
SN-MP（°）	59.37^a	L＜N＜H	59.01^a	L＜N＜H	0.39
OP-FH（°）	11.69^a	L＜N＜H	12.01^a	L＜N＜H	0.08
L₆-MP（°）	6.28^b	H，N＜L	9.68^a	H＜L	0.96
L₆E-RL（mm）	0.56		0.66		0.18
L₆A-RL（mm）	2.49		2.47		0.09
L₆E-MP（mm）	0.19		0.38		0.40
L₆A-MP（mm）	0.01		0.08		0.94
L₄ 间隙（mm）	0.43		0.77		0.43
